| Description： | Horizontal nozzle vacuum band sealer |
Characteristics:
• The sealing bar could be tilted down 0 - 20 degree.
• Outer housing: powder coating or stainless steel housing.
• Available for: foods, chemicals and hardware parts.
• Packing material: any kinds of heat sealable material.
• The length from bag seal to bag lid: max. L 45mm.
• Additional options:
Counter
Date coding machine
Gas extrusion (Nitrogen)
Specifications:
|
|
|
High Efficient horizontal nozzle vacuum band sealer |
|
Model No. |
V-903A |
V-903X |
|
Voltage/Ampere |
1 phase 100V，110V，120V，220V，240V |
1 phase 100V，110V，120V，220V，240V |
|
Machine size |
1350 x 610 x 980-1160 mm |
1560 x 720 x 1010 mm |
|
Sealing width |
5mm or 10mm |
5mm or 10mm |
|
Sealing and conveyor speed |
0-10M/min(adjustable) |
0-10M/min(adjustable) |
|
Bag total thickness |
0.26-0.50 mm |
0.26-0.50 mm |
|
Bag size |
Max L x W： 300 x 300 mm |
Max L X W： 300 x 300 mm |
|
Conveyor width |
200mm |
200mm |
|
Conveyor height adjusting range |
130mm |
130mm |
|
Conveyor loading weight |
5 kgs |
5 kgs |
|
Packing |
1430 x 690 x 1130 mm |
1660 x 820 x 1110 mm |
