CX12085
型號: | Magnetic Buzzer他激式蜂鳴器 |
規格: | OD12*8.5mm,3Vo-p,Freq.:2048Hz |
描述: | BUZZER, External Drive Magnetic Buzzer |
No. | Item | Unit | Specification | Condition |
1 | Oscillation Frequency | Hz | 2048 | Vo-p=1/2duty , square wave |
2 | Operating Voltage | Vo-p | 2~ 4 | |
3 | Rated Voltage< | Vo-p | 3 | |
4 | Current Consumption | mA | MAX. 65 | at Rated Voltage |
5 | Sound Pressure Level | dB | MIN. 85 | at 10cm at Rated Voltage |
6 | Coil Resistance (Ω) | 16±3 | ||
7 | Weight (MAX) | gram | 1 | |
8 | Housing Material | PPO Black ) |
Unit :mm Tol: ±0.5
